# SGR-2 Series

RCCB SERIES Residual Current Circuit Breaker

Products Overview of Residual Current Protective Devices

Product name RCCB

Product range SGR

Product picture

| 10 13 16-20 | 1.5 1.5 2.5 2.0 |  |
| --- | --- | --- |
| 25 32 40 | 4 6 10 |  |
| Types Type AC : For which tripping is ensured for residual sinusoidal alternating currents, whether suddenly applied or slowly rising. |  |  |
| Type A : For which tripping whether suddenly applied or Type G : RCD with short-te | is ensued for residual sinusoidal alternating currents and residual pulsating direct currents, slowly rising. rm delay, with non-operation time of at least 10 ms. |  |
| ·Increased resistance to peak ·Upper limit of tripping time additional protection. | currents to 3 kA (8/20 us). is the same as in RCDs for general use - with | sensitivity of 30 mA fulfils the conditions of |
| ·Limitation of unwanted tripp ·lt is not specified in IEC stan Overall and mountin | ing of RCDs by shor tcurrent surges (coordination with class Il and Ill surge voltage protectors) etc dards, but resistance to undesirable tripping cannot be guaranteed without it. g dimensions |  |

SGR-2 Series Residual Current Circuit Breaker

| Standard | EN/IEC61008-1 |
| --- | --- |
| Rated conditional shor-t circuit current(kA) | 6,10 |
| Rated current(A),ln | 16,20,25,32,40,50,63,80 |
| Number of poles | 2P(1P+N),4P(3P+N) |
| Rated sensitivity currents(mA),IΔn | 10,30,100,300 |
| Rated residual non-operating current | 0.5XIΔn |
| Rated impulse withstand voltage Uimp(kV) | 4 |
| Rated voltage(V) ng time of residual current | 2pole AC 240 |
|  | 4pole AC 415 |
| Ambient temperature (°C) Max.br In(A) IΔn(A) IΔn | -25~+40,Max.95%humidity eaking time 2 IΔn 5 IΔn 5-500A |
| Residual current of-f -time at IΔn 6-40 0.03,0.1,0.3 0.1s | ≤0.1s 0.08s 0.04s 0.04s |
| Rated residual current making & breaking capacity, IΔm | 500A for ln=16,25,32,40,50A 630A for In=63A 800A for In=80A |
| Type of trip | Electro-magnetic release |
| Terminal capacity | Cables up to 25mm2 |
| Protection degree | IP20 |
| Installation | 35mm DIN rail |
| Certification |  |
| SGR-2-2P SGR-2-4P |  |

SGR-2 Series Residual Current Circuit Breaker

|  | Rated current(A) | IΔn | Type AC | Type A | Packing unit |
| --- | --- | --- | --- | --- | --- |
| SGR-2-2P | 16 | 10mA | SGR-2/2/16/10 | SGR-2/2/16/10-A | 6 |
|  | 20 |  | SGR-2/2/20/10 | SGR-2/2/20/10-A |  |
|  | 25 |  | SGR-2/2/25/10 | SGR-2/2/25/10-A |  |
|  | 16 | 30mA | SGR-2/2/16/30 | SGR-2/2/16/30-A |  |
|  | 20 |  | SGR-2/2/20/30 | SGR-2/2/20/30-A |  |
|  | 25 |  | SGR-2/2/25/30 | SGR-2/2/25/30-A |  |
|  | 32 |  | SGR-2/2/32/30 | SGR-2/2/32/30-A |  |
|  | 40 |  | SGR-2/2/40/30 | SGR-2/2/40/30-A |  |
|  | 50 |  | SGR-2/2/50/30 | SGR-2/2/50/30-A |  |
|  | 63 |  | SGR-2/2/63/30 | SGR-2/2/63/30-A |  |
|  | 80 |  | SGR-2/2/80/30 | SGR-2/2/80/30-A |  |
|  | 16 | 100mA | SGR-2/2/16/100 | SGR-2/2/16/100-A |  |
|  | 20 |  | SGR-2/2/20/100 | SGR-2/2/20/100-A |  |
|  | 25 |  | SGR-2/2/25/100 | SGR-2/2/25/100-A |  |
|  | 32 |  | SGR-2/2/32/100 | SGR-2/2/32/100-A |  |
|  | 40 |  | SGR-2/2/40/100 | SGR-2/2/40/100-A |  |
|  | 50 |  | SGR-2/2/50/100 | SGR-2/2/50/100-A |  |
|  | 63 |  | SGR-2/2/63/100 | SGR-2/2/63/100-A |  |
|  | 80 |  | SGR-2/2/80/100 | SGR-2/2/80/100-A |  |
|  | 16 | 300mA | SGR-2/2/16/300 | SGR-2/2/16/300-A |  |
|  | 20 |  | SGR-2/2/20/300 | SGR-2/2/20/300-A |  |
|  | 25 |  | SGR-2/2/25/300 | SGR-2/2/25/300-A |  |
|  | 32 |  | SGR-2/2/32/300 | SGR-2/2/32/300-A |  |
|  | 40 |  | SGR-2/2/40/300 | SGR-2/2/40/300-A |  |
|  | 50 |  | SGR-2/2/50/300 | SGR-2/2/50/300-A |  |
|  | 63 |  | SGR-2/2/63/300 | SGR-2/2/63/300-A |  |
|  | 80 |  | SGR-2/2/80/300 | SGR-2/2/80/300-A |  |
| SGR-2-4P | 16 | 10mA | SGR-2/4/16/10 | SGR-2/4/16/10-A | 3 |
|  | 20 |  | SGR-2/4/20/10 | SGR-2/4/20/10-A |  |
|  | 25 |  | SGR-2/4/25/10 | SGR-2/4/25/10-A |  |
|  | 16 | 30mA | SGR-2/4/16/30 | SGR-2/4/16/30-A |  |
|  | 20 |  | SGR-2/4/20/30 | SGR-2/4/20/30-A |  |
|  | 25 |  | SGR-2/4/25/30 | SGR-2/4/25/30-A |  |
|  | 32 |  | SGR-2/4/32/30 | SGR-2/4/32/30-A |  |
|  | 40 |  | SGR-2/4/40/30 | SGR-2/4/40/30-A |  |
|  | 50 |  | SGR-2/4/50/30 | SGR-2/4/50/30-A |  |
|  | 63 |  | SGR-2/4/63/30 | SGR-2/4/63/30-A |  |
|  | 80 |  | SGR-2/4/80/30 | SGR-2/4/80/30-A |  |
|  | 16 | 100mA | SGR-2/4/16/100 | SGR-2/4/16/100-A |  |
|  | 20 |  | SGR-2/4/20/100 | SGR-2/4/20/100-A |  |
|  | 25 |  | SGR-2/4/25/100 | SGR-2/4/25/100-A |  |
|  | 32 |  | SGR-2/4/32/100 | SGR-2/4/32/100-A |  |
|  | 40 |  | SGR-2/4/40/100 | SGR-2/4/40/100-A |  |
|  | 50 |  | SGR-2/4/50/100 | SGR-2/4/50/100-A |  |
|  | 63 |  | SGR-2/4/63/100 | SGR-2/4/63/100-A |  |
|  | 80 |  | SGR-2/4/80/100 | SGR-2/4/80/100-A |  |
|  | 16 | 300mA | SGR-2/4/16/300 | SGR-2/4/16/300-A |  |
|  | 20 |  | SGR-2/4/20/300 | SGR-2/4/20/300-A |  |
|  | 25 |  | SGR-2/4/25/300 | SGR-2/4/25/300-A |  |
|  | 32 |  | SGR-2/4/32/300 | SGR-2/4/32/300-A |  |
|  | 40 |  | SGR-2/4/40/300 | SGR-2/4/40/300-A |  |
|  | 50 |  | SGR-2/4/50/300 | SGR-2/4/50/300-A |  |
|  | 63 |  | SGR-2/4/63/300 | SGR-2/4/63/300-A |  |
|  | 80 |  | SGR-2/4/80/300 | SGR-2/4/80/300-A |  |

SGR-2 Series Residual Current Circuit Breaker Life

Breaking time of residual current

Wiring (The suitable conductors should be used for connection,see table below for relative parameters)

Features When designing residual current devices, manufacturing technology and type of routine tests, the lEC / EN 61008-1 standards were considered.Important features are: Up to date design User-friendly connection of conductors and busbars Resistance to current surges; unwanted tripping excluded Simple and solid fixing to a 35 mm mounting rail in compliance with EN 60715 Additional colour display of main contacts position (red:contacts closed, green:contacts open) Overall and mounting dimensions

SGR-2

|  | A |  | A |
| --- | --- | --- | --- |
|  | M |  |  |
|  |  |  | M |
|  | E |  |  |

| X G |  |  |  |  |  |
| --- | --- | --- | --- | --- | --- |
| A |  |  |  | X |  |
| M |  |  |  | A |  |

| E |  |  |
| --- | --- | --- |
|  | E |  |
|  | G |  |
|  | X |  |
|  | A |  |
|  | M |  |
