# EPB-63Me-Ne-Se Series <!-- source-page:1 --> MCB SERIES Miniature Circuit Breaker <!-- source-page:2 --> Products Overview of Circuit Breakers Product name MCB | Product range | EPB-63Me | EPB-63Ne | EPB-63Se | | --- | --- | --- | --- | | Product picture | | | | | Standard | IEC/EN 60898-1 GB/T 10963.1 | | | | Number of poles | 1P,2P,3P,4P,(1P+N),(3P+N) | | | | Electrical characteristics | | | | | Rated current(A) In | 1-63 | | | | Rated voltage(V) | 1P AC 230/400;240/415 1P+N AC 230/240 2P AC 230/240;400/415 3P,3P+N,4P AC 400/415 | | | | AC rated shor-t circuit capacity(kA) | | | | | IEC60898-1 standard(kA) | 6 | 4.5 | 3 | | Tripping curev | B,C | | | | Type | AC | | | | Electrical auxiliaries | - | | | | Catalogue page NO. | 60-63 | | | <!-- source-page:3 --> EPB-63Me/Ne/Se Series Miniature Circuit Breaker | Standard | EN/IEC 60898-1 GB/T 10963.1 | | --- | --- | | Breaking capacity(kA) | 3,4.5,6 | | Protection | Against overload and short circuit | | Rated current(A) In | 1,2,3,4,6,10,13,16,20,25,32,40,50,63 | | Rated voltage(V) | 1P AC 230/400,240/415;1P+N AC 230/240 | | | 2P AC230/400,240/415;3P,3P+N,4P AC230/240 | | Rated impulse withstand voltage Uimp(kV) | 4 | | Rated insulation voltage Ui(V) | 500 | | Energy limiting class | 3 | | Ambient temperature (℃) | -25~+40,Max.95%humidity | | Thermal operating limit | 1.13 xIn No tripping within an hour | | | 1.45 xIn Tripping within an hour | | Magnertic operating | B:(3-5)xIn,C:(5-10)xIn | | Number of poles | 1P,1P+N,2P,3P,3P+N and 4P | | Type of trip | Thermal/ magnetic release | | Terminal capacity | 16mm2 flexible or 25mm2 rigid | | Protection degree | IP20 | | Installation | Mounting on 35mm DIN rail | | Width | 17.8mm per pole | | Certification | | | EPB-63Me-1P EPB-63Me-2P EPB-63Me-3P EPB-63Me-4P | | <!-- source-page:4 --> EPB-63Me/Ne/Se Series Miniature Circuit Breaker C curve Rated current(A) Packing unit 4.5 kA 6 kA 3 kA 1 EPB-63Me/1-C1 EPB-63Ne/1-C1 EPB-63Se/1-C1 2 EPB-63Me/1-C2 EPB-63Ne/1-C2 EPB-63Se/1-C2 3 EPB-63Me/1-C3 EPB-63Ne/1-C3 EPB-63Se/1-C3 4 EPB-63Me/1-C4 EPB-63Ne/1-C4 EPB-63Se/1-C4 6 EPB-63Me/1-C6 EPB-63Ne/1-C6 EPB-63Se/1-C6 10 EPB-63Me/1-C10 EPB-63Ne/1-C10 EPB-63Se/1-C10 13 EPB-63Me/1-C13 EPB-63Ne/1-C13 EPB-63Se/1-C13 12 16 EPB-63Me/1-C16 EPB-63Ne/1-C16 EPB-63Se/1-C16 20 EPB-63Me/1-C20 EPB-63Ne/1-C20 EPB-63Se/1-C20 25 EPB-63Me/1-C25 EPB-63Ne/1-C25 EPB-63Se/1-C25 32 EPB-63Me/1-C32 EPB-63Ne/1-C32 EPB-63Se/1-C32 40 EPB-63Me/1-C40 EPB-63Ne/1-C40 EPB-63Se/1-C40 EPB-63Me-1P 50 EPB-63Me/1-C50 EPB-63Ne/1-C50 EPB-63Se/1-C50 63 EPB-63Me/1-C63 EPB-63Ne/1-C63 EPB-63Se/1-C63 1 EPB-63Me/1-C1N EPB-63Ne/1-C1N EPB-63Se/1-C1N 2 EPB-63Me/1-C2N EPB-63Ne/1-C2N EPB-63Se/1-C2N 3 EPB-63Me/1-C3N EPB-63Ne/1-C3N EPB-63Se/1-C3N 4 EPB-63Me/1-C4N EPB-63Ne/1-C4N EPB-63Se/1-C4N 6 EPB-63Me/1-C6N EPB-63Ne/1-C6N EPB-63Se/1-C6N 10 EPB-63Me/1-C10N EPB-63Ne/1-C10N EPB-63Se/1-C10N 13 EPB-63Me/1-C13N EPB-63Ne/1-C13N EPB-63Se/1-C13N 6 16 EPB-63Me/1-C16N EPB-63Ne/1-C16N EPB-63Se/1-C16N 20 EPB-63Me/1-C20N EPB-63Ne/1-C20N EPB-63Se/1-C20N 25 EPB-63Me/1-C25N EPB-63Ne/1-C25N EPB-63Se/1-C25N 32 EPB-63Me/1-C32N EPB-63Ne/1-C32N EPB-63Se/1-C32N 40 EPB-63Me/1-C40N EPB-63Ne/1-C40N EPB-63Se/1-C40N EPB-63Me-1P+N 50 EPB-63Me/1-C50N EPB-63Ne/1-C50N EPB-63Se/1-C50N 63 EPB-63Me/1-C63N EPB-63Ne/1-C63N EPB-63Se/1-C63N 1 EPB-63Me/2-C1 EPB-63Ne/2-C1 EPB-63Se/2-C1 2 EPB-63Me/2-C2 EPB-63Ne/2-C2 EPB-63Se/2-C2 3 EPB-63Me/2-C3 EPB-63Ne/2-C3 EPB-63Se/2-C3 4 EPB-63Me/2-C4 EPB-63Ne/2-C4 EPB-63Se/2-C4 6 EPB-63Me/2-C6 EPB-63Ne/2-C6 EPB-63Se/2-C6 10 EPB-63Me/2-C10 EPB-63Ne/2-C10 EPB-63Se/2-C10 13 EPB-63Me/2-C13 EPB-63Ne/2-C13 EPB-63Se/2-C13 6 16 EPB-63Me/2-C16 EPB-63Ne/2-C16 EPB-63Se/2-C16 20 EPB-63Me/2-C20 EPB-63Ne/2-C20 EPB-63Se/2-C20 25 EPB-63Me/2-C25 EPB-63Ne/2-C25 EPB-63Se/2-C25 32 EPB-63Me/2-C32 EPB-63Ne/2-C32 EPB-63Se/2-C32 40 EPB-63Me/2-C40 EPB-63Ne/2-C40 EPB-63Se/2-C40 EPB-63Me-2P 50 EPB-63Me/2-C50 EPB-63Ne/2-C50 EPB-63Se/2-C50 63 EPB-63Me/2-C63 EPB-63Ne/2-C63 EPB-63Se/2-C63 <!-- source-page:5 --> EPB-63Me/Ne/Se Series Miniature Circuit Breaker C curve Rated current(A) Packing unit 4.5 kA 6 kA 3 kA 1 EPB-63Me/3-C1 EPB-63Ne/3-C1 EPB-63Se/3-C1 2 EPB-63Me/3-C2 EPB-63Ne/3-C2 EPB-63Se/3-C2 3 EPB-63Me/3-C3 EPB-63Ne/3-C3 EPB-63Se/3-C3 4 EPB-63Me/3-C4 EPB-63Ne/3-C4 EPB-63Se/3-C4 6 EPB-63Me/3-C6 EPB-63Ne/3-C6 EPB-63Se/3-C6 10 EPB-63Me/3-C10 EPB-63Ne/3-C10 EPB-63Se/3-C10 13 EPB-63Me/3-C13 EPB-63Ne/3-C13 EPB-63Se/3-C13 4 16 EPB-63Me/3-C16 EPB-63Ne/3-C16 EPB-63Se/3-C16 20 EPB-63Me/3-C20 EPB-63Ne/3-C20 EPB-63Se/3-C20 25 EPB-63Me/3-C25 EPB-63Ne/3-C25 EPB-63Se/3-C25 32 EPB-63Me/3-C32 EPB-63Ne/3-C32 EPB-63Se/3-C32 40 EPB-63Me/3-C40 EPB-63Ne/3-C40 EPB-63Se/3-C40 EPB-63Me-3P 50 EPB-63Me/3-C50 EPB-63Ne/3-C50 EPB-63Se/3-C50 63 EPB-63Me/3-C63 EPB-63Ne/3-C63 EPB-63Se/3-C63 1 EPB-63Me/3-C1N EPB-63Ne/3-C1N EPB-63Se/3-C1N 2 EPB-63Me/3-C2N EPB-63Ne/3-C2N EPB-63Se/3-C2N 3 EPB-63Me/3-C3N EPB-63Ne/3-C3N EPB-63Se/3-C3N 4 EPB-63Me/3-C4N EPB-63Ne/3-C4N EPB-63Se/3-C4N 6 EPB-63Me/3-C6N EPB-63Ne/3-C6N EPB-63Se/3-C6N 10 EPB-63Me/3-C10N EPB-63Ne/3-C10N EPB-63Se/3-C10N 13 EPB-63Me/3-C13N EPB-63Ne/3-C13N EPB-63Se/3-C13N 3 16 EPB-63Me/3-C16N EPB-63Ne/3-C16N EPB-63Se/3-C16N 20 EPB-63Me/3-C20N EPB-63Ne/3-C20N EPB-63Se/3-C20N 25 EPB-63Me/3-C25N EPB-63Ne/3-C25N EPB-63Se/3-C25N 32 EPB-63Me/3-C32N EPB-63Ne/3-C32N EPB-63Se/3-C32N 40 EPB-63Me/3-C40N EPB-63Ne/3-C40N EPB-63Se/3-C40N EPB-63Me-3P+N 50 EPB-63Me/3-C50N EPB-63Ne/3-C50N EPB-63Se/3-C50N 63 EPB-63Me/3-C63N EPB-63Ne/3-C63N EPB-63Se/3-C63N 1 EPB-63Me/4-C1 EPB-63Ne/4-C1 EPB-63Se/4-C1 2 EPB-63Me/4-C2 EPB-63Ne/4-C2 EPB-63Se/4-C2 3 EPB-63Me/4-C3 EPB-63Ne/4-C3 EPB-63Se/4-C3 4 EPB-63Me/4-C4 EPB-63Ne/4-C4 EPB-63Se/4-C4 6 EPB-63Me/4-C6 EPB-63Ne/4-C6 EPB-63Se/4-C6 10 EPB-63Me/4-C10 EPB-63Ne/4-C10 EPB-63Se/4-C10 13 EPB-63Me/4-C13 EPB-63Ne/4-C13 EPB-63Se/4-C13 3 16 EPB-63Me/4-C16 EPB-63Ne/4-C16 EPB-63Se/4-C16 20 EPB-63Me/4-C20 EPB-63Ne/4-C20 EPB-63Se/4-C20 25 EPB-63Me/4-C25 EPB-63Ne/4-C25 EPB-63Se/4-C25 32 EPB-63Me/4-C32 EPB-63Ne/4-C32 EPB-63Se/4-C32 40 EPB-63Me/4-C40 EPB-63Ne/4-C40 EPB-63Se/4-C40 EPB-63Me-4P 50 EPB-63Me/4-C50 EPB-63Ne/4-C50 EPB-63Se/4-C50 63 EPB-63Me/4-C63 EPB-63Ne/4-C63 EPB-63Se/4-C63 <!-- source-page:6 --> EPB-63Me/Ne/Se Series Miniature Circuit Breaker Curves Overcurrent protecting characteristics Rated current of release(A) Test current Specified time Initial state NO. Result to be obtained Remarks 1.13In t≤1h 1-63 cold state upon the previous test 1 Non-trip Setting current up to specified value steadily in 5s 1.45In t<1h 1-63 2 trip 1s<t<60s In≤32 2.55In 3 trip cold state In>32 1s<t<120s 3In t≤0.1s Non-trip B type 5ln t<0.1s trip 5In t≤0.1s Non-trip C type 10ln t<0.1s trip 4 cold state 1-63 Endurance(operations) Category Operations Operation frequency Rated current Electrical endurance 4000 240/h 1-32 120/h 40-63 Mechanical endurance 240/h 1-63 10000 Features Much higher short circuit breaking capacity, Dual-connection convenient for both standard busbar and conductor connection. Improved safety of operators offered by special design from terminals. Much longer service life thanks to energy-storage operating mechanism.Enclosure and functional parts made from imported plastics with flame-retardant, heat-resistant, and impulse-proof properties.Higher current-limiting capacity ensuring a cost-effective range of products. Different handle color for different rated current with contactor condition indicator. Overall and mounting dimensions EPB-63Me/EPB-63Se/EPB-63Ne
