# SGBR-32M-H Series

RCBO SERIES Residual Current Circuit Breakers with Overcurrent Protection

Products Overview of Residual Current Protective Devices

Product name

Product range

Product picture

Standard

Number of poles

Rated current(A) In

Rated voltage(V)

Rated residual current(mA)

Rated conditional short-circuit current(kA)

Tripping curve

Residual current operating characteristic

Catalogue page NO.

RCBO

SGBR-32M/H

IEC/EN 61009-1

1P+N

Electrical characteristics

6~32

AC 230/240

10,30,100,300

4.5,6

B,C

AC,A

33-36

SGBR-32M/H Series Residual Current Circuit Breakers with Overcurrent Protection Standard EN/IEC 61009-1 Rated conditional short-circuit current(kA) 4.5,6 Rated current(A),ln 6,10,13,16,20,25,32 Number of poles 1P+N Rated sensitivity currents(mA),IΔn 10,30,100,300 Tripping curve B,C Rated residual non-operating current 0.5XIΔn Rated impulse withstand voltage Uimp(kV) 4 Rated voltage(V) AC 230/240 Ambient temperature (°C) -25~+40,Max.95%humidity Residual current off time ≤0.1s

Type of trip

Electrical endurance 4000 Mechanical endurance 10000 Terminal capacity 10mm2 flexible/16mm2 rigid Protection degree IP20 Installation 35mm DIN rail

Ground fault Electronic Thermal-magnetic Over current

SGBR-32M SGBR-32H

Type AC Residual Current Circuit Breakers with Overcurrent Protection SGBR-32M Type A Rated current(A) IΔn Packing unit C curve B curve B curve C curve 6 SGBR-32M/B6/10 SGBR-32M/B6/10-A SGBR-32M/C6/10 SGBRi-6K/C6/10-A 10 SGBR-32M/B10/10 SGBR-32M/B10/10-A SGBR-32M/C10/10 SGBRi-6K/C10/10-A 13 SGBR-32M/B13/10 SGBR-32M/B13/10-A SGBR-32M/C13/10 SGBRi-6K/C13/10-A 10mA 16 SGBR-32M/B16/10 SGBR-32M/B16/10-A SGBR-32M/C16/10 SGBRi-6K/C16/10-A 20 SGBR-32M/B20/10 SGBR-32M/B20/10-A SGBR-32M/C20/10 SGBR-32M/C20/10-A 25 SGBR-32M/B25/10 SGBR-32M/B25/10-A SGBR-32M/C25/10 SGBR-32M/C25/10-A 32 SGBR-32M/B32/10 SGBR-32M/B32/10-A SGBR-32M/C32/10 SGBR-32M/C32/10-A 6 SGBR-32M/B6/30 SGBR-32M/B6/30-A SGBR-32M/C6/30 SGBR-32M/C6/30-A 10 SGBR-32M/B10/30 SGBR-32M/B10/30-A SGBR-32M/C10/30 SGBR-32M/C10/30-A 13 SGBR-32M/B13/30 SGBR-32M/B13/30-A SGBR-32M/C13/30 SGBR-32M/C13/30-A 30mA 16 SGBR-32M/B16/30 SGBR-32M/B16/30-A SGBR-32M/C16/30 SGBR-32M/C16/30-A Type AC 20 SGBR-32M/B20/30 SGBR-32MB20/30-A SGBR-32M/C20/30 SGBR-32M/C20/30-A 25 SGBR-32M/B25/30 SGBR-32M/B25/30-A SGBR-32M/C25/30 SGBR-32M/C25/30-A 32 SGBR-32M/B32/30 SGBR-32M/B32/30-A SGBR-32M/C32/30 SGBR-32M/C32/30-A 12 6 SGBR-32M/B6/100 SGBR-32M/B6/100-A SGBR-32M/C6/100 SGBR-32M/C6/100-A 10 SGBR-32M/B10/100 SGBR-32M/B10/100-A SGBR-32M/C10/100 SGBR-32M/C10/100-A 13 SGBR-32M/B13/100 SGBR-32M/B13/100-A SGBR-32M/C13/100 SGBR-32M/C13/100-A 16 SGBR-32M/B16/100 SGBR-32M/B16/100-A SGBR-32M/C16/100 SGBR-32M/C16/100-A 100mA 20 SGBR-32M/B20/100 SGBR-32M/B20/100-A SGBR-32M/C20/100 SGBR-32M/C20/100-A 25 SGBR-32M/B25/100 SGBR-32M/B25/100-A SGBR-32M/C25/100 SGBR-32M/C25/100-A 32 SGBR-32M/B32/100 SGBR-32M/B32/100-A SGBR-32M/C32/100 SGBR-32M/C32/100-A 6 SGBR-32M/B6/300 SGBR-32M/B6/300-A SGBR-32M/C6/300 SGBR-32M/C6/300-A Type A 10 SGBR-32M/B10/300 SGBR-32M/B10/300-A SGBR-32M/C10/300 SGBR-32M/C10/300-A 13 SGBR-32M/B13/300 SGBR-32M/B13/300-A SGBR-32M/C13/300 SGBR-32M/C13/300-A 16 SGBR-32M/B16/300 SGBR-32M/B16/300-A SGBR-32M/C16/300 SGBR-32M/C16/300-A 300mA 20 SGBR-32M/B20/300 SGBR-32M/B20/300-A SGBR-32M/C20/300 SGBR-32M/C20/300-A 25 SGBR-32M/B25/300 SGBR-32M/B25/300-A SGBR-32M/C25/300 SGBR-32M/C25/300-A 32 SGBR-32M/B32/300 SGBR-32M/B32/300-A SGBR-32M/C32/300 SGBR-32M/C32/300-A

Type AC Residual Current Circuit Breakers with Overcurrent Protection SGBR-32H Type A Rated current(A) IΔn Packing unit C curve B curve B curve C curve 6 SGBR-32H/B6/10 SGBR-32H/B6/10-A SGBR-32H/C6/10 SGBR-32H/C6/10-A 10 SGBR-32H/B10/10 SGBR-32H/B10/10-A SGBR-32H/C10/10 SGBR-32H/C10/10-A 13 SGBR-32H/B13/10 SGBR-32H/B13/10-A SGBR-32H/C13/10 SGBR-32H/C13/10-A 10mA 16 SGBR-32H/B16/10 SGBR-32H/B16/10-A SGBR-32H/C16/10 SGBR-32H/C16/10-A 20 SGBR-32H/B20/10 SGBR-32H/B20/10-A SGBR-32H/C20/10 SGBR-32H/C20/10-A 25 SGBR-32H/B25/10 SGBR-32H/B25/10-A SGBR-32H/C25/10 SGBR-32H/C25/10-A 32 SGBR-32H/B32/10 SGBR-32H/B32/10-A SGBR-32H/C32/10 SGBR-32H/C32/10-A 6 SGBR-32H/B6/30 SGBR-32H/B6/30-A SGBR-32H/C6/30 SGBR-32H/C6/30-A 10 SGBR-32H/B10/30 SGBR-32H/B10/30-A SGBR-32H/C10/30 SGBR-32H/C10/30-A 13 SGBR-32H/B13/30 SGBR-32H/B13/30-A SGBR-32H/C13/30 SGBR-32H/C13/30-A 30mA 16 SGBR-32H/B16/30 SGBR-32H/B16/30-A SGBR-32H/C16/30 SGBR-32H/C16/30-A Type AC 20 SGBR-32H/B20/30 SGBR-32H/B20/30-A SGBR-32H/C20/30 SGBR-32H/C20/30-A 25 SGBR-32H/B25/30 SGBR-32H/B25/30-A SGBR-32H/C25/30 SGBR-32H/C25/30-A 32 SGBR-32H/B32/30 SGBR-32H/B32/30-A SGBR-32H/C32/30 SGBR-32H/C32/30-A 12 6 SGBR-32H/B6/100 SGBR-32H/B6/100-A SGBR-32H/C6/100 SGBR-32H/C6/100-A 10 SGBR-32H/B10/100 SGBR-32H/B10/100-A SGBR-32H/C10/100 SGBR-32H/C10/100-A 13 SGBR-32H/B13/100 SGBR-32H/B13/100-A SGBR-32H/C13/100 SGBR-32H/C13/100-A 16 SGBR-32H/B16/100 SGBR-32H/B16/100-A SGBR-32H/C16/100 SGBR-32H/C16/100-A 100mA 20 SGBR-32H/B20/100 SGBR-32H/B20/100-A SGBR-32H/C20/100 SGBR-32H/C20/100-A 25 SGBR-32H/B25/100 SGBR-32H/B25/100-A SGBR-32H/C25/100 SGBR-32H/C25/100-A 32 SGBR-32H/B32/100 SGBR-32H/B32/100-A SGBR-32H/C32/100 SGBR-32H/C32/100-A 6 SGBR-32H/B6/300 SGBR-32H/B6/300-A SGBR-32H/C6/300 SGBR-32H/C6/300-A Type A 10 SGBR-32H/B10/300 SGBR-32H/B10/300-A SGBR-32H/C10/300 SGBR-32H/C10/300-A 13 SGBR-32H/B13/300 SGBR-32H/B13/300-A SGBR-32H/C13/300 SGBR-32H/C13/300-A 16 SGBR-32H/B16/300 SGBR-32H/B16/300-A SGBR-32H/C16/300 SGBR-32H/C16/300-A 300mA 20 SGBR-32H/B20/300 SGBR-32H/B20/300-A SGBR-32H/C20/300 SGBR-32H/C20/300-A 25 SGBR-32H/B25/300 SGBR-32H/B25/300-A SGBR-32H/C25/300 SGBR-32H/C25/300-A 32 SGBR-32H/B32/300 SGBR-32H/B32/300-A SGBR-32H/C32/300 SGBR-32H/C32/300-A

SGBR-32M/H Series Residual Current Circuit Breakers with Overcurrent Protection Curves

Breaking time of residual current Max.breaking time In(A) IΔn(A) IΔn 2 IΔn 5 IΔn 5A-500A 6-32 0.01,0.03,0.1,0.3 0.1s 0.08s 0.04s 0.04s Wiring (The suitable conductors should be used for connection,see table below for relative parameters) Cross section area s(mm2) Tightening torque(N.m) Rated current In (A)

Features Switching and isolation function. Protection against overload and short-circuit currents. Protection against the effects of sinusoidal alternating earth fault currents. Protection against indirect contacts and additional protection against direct contacts. Protection against fire hazard caused by insulation faults. Used in residential building and distribution boards. Overall and mounting dimensions

6 1 1.5 10 1.2 2.5 16-20 4 25 6 32

SGBR-32M/H
