# EPR-2 Series

RCCB SERIES Residual Current Circuit Breaker

Products Overview of Residual Current Protective Devices

Product name RCCB

Product range

Product picture

Standard

Number of poles

Rated current(A) In

Rated voltage(V)

Rated residual current(mA)

Rated conditional short-circuit current(kA)

Tripping curve

Residual current operating characteristic

Catalogue page NO.

EPR-2

IEC/EN 61008-1

2P(1P+N) 4P(3P+N)

Electrical characteristics

16~80

AC 240 AC 415

10,30,100,300

6,10

------

AC,A,S

03-05

EPR-2 Series Residual Current Circuit Breaker

| Standard Curev s | EN/IEC61008-1 |
| --- | --- |
| Rated conditional shor-t circuit current(kA) | 6,10 |
| Rated current(A),ln | 16,20,25,32,40,50,63,80 |
| Number of poles | 2P(1P+N),4P(3P+N) |
| Rated sensitivity currents(mA),IΔn | 10,30,100,300 |
| Rated residual non-operating current | 0.5XIΔn |
| Rated impulse withstand voltage Uimp(kV) | 4 |
| Rated voltage(V) Breaking time of residual current | 2pole AC 240 |
|  | 4pole AC 415 |
| Ambient temperature (°C) Max.br In(A) IΔn(A) IΔn | -25~+40,Max.95%humidity eaking time 2 IΔn 5 IΔn 5-500A |
| Residual current of-f -time at IΔn 6-40 0.03,0.1,0.3 0.1s | ≤0.1s 0.08s 0.04s 0.04s |
| Rated residual current making & breaking capacity, IΔm Wiring (The suitable conductors should be used for Rated current In (A) Cross sect 6 10 13 | 500A for ln=16,25,32,40,50A 630A for In=63A 800A for In=80A connection,see table below for relative parameters) ion area s(mm2) Tightening torque(N.m) 1 1.5 1.5 |
| Type of trip 16-20 | Electro-magnetic release 2.5 2.0 |
| Terminal capacity 25 32 | Cables up to 25mm2 4 6 |
| Protection degree 40 | IP20 10 |
| Installation Types | 35mm DIN rail |
| Certification |  |
| EPR-2-2P EPR-2-4P sistance to peak currents to 3 kA (8/20 us). ·Upper limit of tripping time is the same as in RCDs for general use - with sensitivity of 30 mA fulfils the conditions of additional protection. ·Limitation of unwanted tripping of RCDs by shor tcurrent surges (coordination with class Il and Ill surge voltage protectors) etc ·lt is not specified in IEC standards, but resistance to undesirable tripping cannot be guaranteed without it. Overall and mounting dimensions |  |

EPR-2 Series Residual Current Circuit Breaker

|  | Rated current(A) | IΔn | Type AC | Type A | Packing unit |
| --- | --- | --- | --- | --- | --- |
| EPR-2-2P | 16 | 10mA | EPR-2/2/16/10 | EPR-2/2/16/10-A | 6 |
|  | 20 |  | EPR-2/2/20/10 | EPR-2/2/20/10-A |  |
|  | 25 |  | EPR-2/2/25/10 | EPR-2/2/25/10-A |  |
|  | 16 | 30mA | EPR-2/2/16/30 | EPR-2/2/16/30-A |  |
|  | 20 |  | EPR-2/2/20/30 | EPR-2/2/20/30-A |  |
|  | 25 |  | EPR-2/2/25/30 | EPR-2/2/25/30-A |  |
|  | 32 |  | EPR-2/2/32/30 | EPR-2/2/32/30-A |  |
|  | 40 |  | EPR-2/2/40/30 | EPR-2/2/40/30-A |  |
|  | 50 |  | EPR-2/2/50/30 | EPR-2/2/50/30-A |  |
|  | 63 |  | EPR-2/2/63/30 | EPR-2/2/63/30-A |  |
|  | 80 |  | EPR-2/2/80/30 | EPR-2/2/80/30-A |  |
|  | 16 | 100mA | EPR-2/2/16/100 | EPR-2/2/16/100-A |  |
|  | 20 |  | EPR-2/2/20/100 | EPR-2/2/20/100-A |  |
|  | 25 |  | EPR-2/2/25/100 | EPR-2/2/25/100-A |  |
|  | 32 |  | EPR-2/2/32/100 | EPR-2/2/32/100-A |  |
|  | 40 |  | EPR-2/2/40/100 | EPR-2/2/40/100-A |  |
|  | 50 |  | EPR-2/2/50/100 | EPR-2/2/50/100-A |  |
|  | 63 |  | EPR-2/2/63/100 | EPR-2/2/63/100-A |  |
|  | 80 |  | EPR-2/2/80/100 | EPR-2/2/80/100-A |  |
|  | 16 | 300mA | EPR-2/2/16/300 | EPR-2/2/16/300-A |  |
|  | 20 |  | EPR-2/2/20/300 | EPR-2/2/20/300-A |  |
|  | 25 |  | EPR-2/2/25/300 | EPR-2/2/25/300-A |  |
|  | 32 |  | EPR-2/2/32/300 | EPR-2/2/32/300-A |  |
|  | 40 |  | EPR-2/2/40/300 | EPR-2/2/40/300-A |  |
|  | 50 |  | EPR-2/2/50/300 | EPR-2/2/50/300-A |  |
|  | 63 |  | EPR-2/2/63/300 | EPR-2/2/63/300-A |  |
|  | 80 |  | EPR-2/2/80/300 | EPR-2/2/80/300-A |  |
| EPR-2-4P | 16 | 10mA | EPR-2/4/16/10 | EPR-2/4/16/10-A | 3 |
|  | 20 |  | EPR-2/4/20/10 | EPR-2/4/20/10-A |  |
|  | 25 |  | EPR-2/4/25/10 | EPR-2/4/25/10-A |  |
|  | 16 | 30mA | EPR-2/4/16/30 | EPR-2/4/16/30-A |  |
|  | 20 |  | EPR-2/4/20/30 | EPR-2/4/20/30-A |  |
|  | 25 |  | EPR-2/4/25/30 | EPR-2/4/25/30-A |  |
|  | 32 |  | EPR-2/4/32/30 | EPR-2/4/32/30-A |  |
|  | 40 |  | EPR-2/4/40/30 | EPR-2/4/40/30-A |  |
|  | 50 |  | EPR-2/4/50/30 | EPR-2/4/50/30-A |  |
|  | 63 |  | EPR-2/4/63/30 | EPR-2/4/63/30-A |  |
|  | 80 |  | EPR-2/4/80/30 | EPR-2/4/80/30-A |  |
|  | 16 | 100mA | EPR-2/4/16/100 | EPR-2/4/16/100-A |  |
|  | 20 |  | EPR-2/4/20/100 | EPR-2/4/20/100-A |  |
|  | 25 |  | EPR-2/4/25/100 | EPR-2/4/25/100-A |  |
|  | 32 |  | EPR-2/4/32/100 | EPR-2/4/32/100-A |  |
|  | 40 |  | EPR-2/4/40/100 | EPR-2/4/40/100-A |  |
|  | 50 |  | EPR-2/4/50/100 | EPR-2/4/50/100-A |  |
|  | 63 |  | EPR-2/4/63/100 | EPR-2/4/63/100-A |  |
|  | 80 |  | EPR-2/4/80/100 | EPR-2/4/80/100-A |  |
|  | 16 | 300mA | EPR-2/4/16/300 | EPR-2/4/16/300-A |  |
|  | 20 |  | EPR-2/4/20/300 | EPR-2/4/20/300-A |  |
|  | 25 |  | EPR-2/4/25/300 | EPR-2/4/25/300-A |  |
|  | 32 |  | EPR-2/4/32/300 | EPR-2/4/32/300-A |  |
|  | 40 |  | EPR-2/4/40/300 | EPR-2/4/40/300-A |  |
|  | 50 |  | EPR-2/4/50/300 | EPR-2/4/50/300-A |  |
|  | 63 |  | EPR-2/4/63/300 | EPR-2/4/63/300-A |  |
|  | 80 |  | EPR-2/4/80/300 | EPR-2/4/80/300-A |  |

EPR-2 Series Residual Current Circuit Breaker Life

Breaking time of residual current

Wiring (The suitable conductors should be used for connection,see table below for relative parameters)

Features When designing residual current devices, manufacturing technology and type of routine tests, the lEC / EN 61008-1 standards were considered.Important features are: Up to date design User-friendly connection of conductors and busbars Resistance to current surges; unwanted tripping excluded Simple and solid fixing to a 35 mm mounting rail in compliance with EN 60715 Additional colour display of main contacts position (red:contacts closed, green:contacts open) Overall and mounting dimensions

EPR-2

| In | Operating cycles On-load operating cycles Of-f load operating cycles |  | Operating frequency (operations/h) |
| --- | --- | --- | --- |
|  |  | Of-f load operating cycles |  |
| 16,20,25,32 | 2000 | 2000 | 240 |
| 40,50,63,80 | 2000 | 1000 | 120 |

| Max.breaking time |  |  |  |  |  |
| --- | --- | --- | --- | --- | --- |
| In(A) | IΔn(A) | IΔn | 2 IΔn | 5 IΔn | 5-500A |
| 16,20,25,32,40,50,63, | 80 0.01,0.03,0.1,0.3 | 0.1s | 0.08s | 0.04s | 0.04s |

| Rated current In (A) | Cross section area s(mm2) | Tightening torque(N.m) |
| --- | --- | --- |
| 16 | 2.5 | 2.5 |
| 20 | 2.5 |  |
| 25 | 4 |  |
| 32 | 6 |  |
| 40 | 10 |  |
| 50 | 16 |  |
| 63 | 16 |  |
| 80 | 25 |  |
