# EPTF-8 Series

MCB Accessories SERIES EPBA Series MCB Accessory EPSO Series Door Bell EPSL Series Indicating Light

EPSO Series Door Bell Standard EN/IEC 61558-1 Electric ratings 8V,12V,24V,110V,230V 50/60Hz Installation class ll & lll Pollution grade ll Working condition Short-time working Degree of protection IP20 Mounting 35mm DI Nrail EPTF-8 Series Transformer Standard EN/IEC 61558 Input voltage(V) AC 230 Output voltage(V) 4,6,8,12,16,24 Rated power outpu 8VA Consumption(W) 1.15 Pollution class l Mounting 35mm DIN rail Service period Continuous operating Connection terminals Pillar terminal with clamp Connection capacity Rigid conductor 10mm2 Terminal Connection Height H=15.5mm

EPSO EPTF-8

EPSO Series Door Bell

Operational voltage(V) Code NO. Capacity (VA) Noise level Packing unit 8 12 24 110 230 Overall and mounting dimensions

EPTF-8 Series Transformer Coil Temperature rising(℃) Code NO. Rated output power P2(VA) Current w/o Load lo(A) Primary U1(V)

Overall and mounting dimensions

EPSO-8 EPSO-12 EPSO-24 EPSO-110 EPSO-230

EPTF-8-4 EPTF-8-6 EPTF-8-8 230(240) EPTF-8-12 EPTF-8-16 EPTF-8-24

4.8 4.8 4.8 4.4 4.0

Rated voltage Secondary U2(U) 4 6 8 12 16 24

78dB 12

Power consumption w/o Load Po(W)

36±6 1.15 50
