# EPB-63M-DC Series

MCB SERIES Miniature Circuit Breaker

Products Overview of Circuit Breakers

Product name DC MCB

| Product range | EPB-63M-DC |
| --- | --- |
| Product picture |  |
| Standard | GB/T14048.2 IEC/EN 60947-2 |
| Number of poles | 1P,2P,3P,4P |
| Electrical characteristics |  |
| Rated current(A) In | 1-63 |
| Rated voltage(V) | DC 120,240 |
| AC rated shor-t circuit capacity(kA) |  |
| Breaking capacity (Icn/Icu)kA | 6 |
| Tripping curev | 8-12In |
| Type | DC |
| Electrical auxiliaries | - |
| Catalogue page NO. | 70-73 |

EPB-63M-DC Series Miniature Circuit Breaker Standard IEC/EN 60947-2 Breaking capacity(kA) 6 Protection Against overload and short circuit Rated current(A) In 1,2,3,4,6,10,13,16,20,25,32,40,50,63 Rated voltage(V) Operational volatge Ambient temperature (℃) -25~+40,Max.95%humidity Thermal operating limit 1.05 xIn No tripping within an hour

Magnertic operating (8-12)xIn Number of poles 1P,2P,3P and 4P Type of trip Thermal/ magnetic release

Terminal capacity 16mm2 flexible or 25mm2 rigid

Protection degree IP20 Installation Mounting on 35mm DIN rail Width 17.8mm per pole Certification

EPB-63M-DC-1P EPB-63M-DC-2P EPB-63M-DC-3P EPB-63M-DC-4P

1P DC 120;2P,3P,4P DC 240 Min.:12

1.3 xIn Tripping within an hour

EPB-63M-DC Series Miniature Circuit Breaker

DC type Rated current(A) 1 EPB-63M/1-DC1 2 EPB-63M/1-DC2 3 EPB-63M/1-DC3 4 EPB-63M/1-DC4 6 EPB-63M/1-DC6 10 EPB-63M/1-DC10 13 EPB-63M/1-DC13 16 EPB-63M/1-DC16 20 EPB-63M/1-DC20 25 EPB-63M/1-DC25 32 EPB-63M/1-DC32 EPB-63M-DC-1P 40 EPB-63M/1-DC40 50 EPB-63M/1-DC50 63 EPB-63M/1-DC63 1 EPB-63M/2-DC1 2 EPB-63M/2-DC2 3 EPB-63M/2-DC3 4 EPB-63M/2-DC4 6 EPB-63M/2-DC6 10 EPB-63M/2-DC10 13 EPB-63M/2-DC13 16 EPB-63M/2-DC16 20 EPB-63M/2-DC20 25 EPB-63M/2-DC25 EPB-63M-DC-2P 32 EPB-63M/2-DC32 40 EPB-63M/2-DC40 50 EPB-63M/2-DC50 63 EPB-63M/2-DC63

Packing unit

EPB-63M-DC Series Miniature Circuit Breaker

| manufacturer to loc position, locking in t | k the equipment i hat position shall | n the open only be |  |
| --- | --- | --- | --- |
| possible when the position Equipment shall be front plate or cover manner which ensu indication and locki For equipment prov “tripped position” or the indicated open clearly identified. | main contacts are | in the open | N/A |
|  | designed so that | the actuator, |  |
|  | are fitted to the e res correct conta | quipment in a ct position |  |
|  | ng, if provided |  |  |
|  | ided with position “standby position | s such as ”, which are not |  |
|  | position, those po | sitions shall be |  |
|  | d position (N) ..... | ..................... : |  |
|  | stand voltage (kV) | ................... : |  |
|  | main contacts at | the test force |  |
|  | ls which main |  |  |

EPB-63M-DC Series Miniature Circuit Breaker Overcurrent protecting characteristics Rated current of release(A) NO. Initial state Test current Specified time Result to be obtained Remarks 1 1-63 cold state 1.05In t≤1h Non-trip upon the previous test Setting current up to specified value steadily in 5s 2 1-63 1.30In t<1h trip In≤32 1s<t<60s cold state 2.55In trip In>32 1s<t<120s 3 12In 8In trip t<0.2s 1-63 cold state C type Non-trip t≤0.2s Endurance(operations)

Category Operations Operation frequency Rated current Electrical endurance 4000 240/h 1-32 120/h 40-63 Mechanical endurance 10000 240/h 1-63

Features Much higher short circuit breaking capacity, Dual-connection convenient for both standard busbar and conductor connection. Improved safety of operators offered by special design from terminals. Much longer service life thanks to energy-storage operating mechanism.Enclosure and functional parts made from imported plastics with flame-retardant, heat-resistant, and impulse-proof properties.Higher current-limiting capacity ensuring a cost-effective range of products. Different handle color for different rated current with contactor condition indicator.

Overall and mounting dimensions

EPR-63M-DC
