# SGM6-125

Moulded Case Circuit Breaker

Product category Design code Type code Design code Breaking capacity level Pole Rated current SGM e.g. - / 6 : s 125 M 3P 125A

SGM series Moulded Case Circuit Breaker

Thermal Adjustable Type（s） Fixed Type （/）

125A,160A,250A,400A,630A,800A/1000A,1600A

6 Thermal & Magnetic Adjustable Type（sm） Electronic Type with Knobs（E） Electronic Type with LCD（i） With ELCB Type（L）

C*,L,M,H,H max 3P,4P 16-1600A

Fixed Type SGM6 Moulded Case Circuit Breaker

Ratings And Specifications

Frame Size

Model Number of poles 3,4

Rated current(A) In

Magnetic tripping current (Ii) Standard IEC60947-2 Reference temperature 40℃/55℃ Rated operational voltage 380/400/415V AC Rated insulation voltage Ui (V) Rated impluse withstand voltage Uimp (kV) 8 Breaking capacity level Rated ultimate short-circuit breaking capacity Icu(kA) Rated service short-circuit breaking capacity Ics(kA) Icu=Ics(KA)

Mechanical Endurance Electrical Endurance

Installation

125 125

10 for 16-100A 8500 1500

SGM6-125

16,20,25,30,32,40, 50,60,63,70,75,80, 90,100,125 10*In for 32 - 125 A 320A for 16-30 A

800

Fixed Type

M H

25 36

18 25

18 25 for 125A 7000 1000 Auxiliary contact(OF) Alarm switch(SD) Shunt tirp(MX) Under-voltage release(MN) AC Motor Mechanism Extended Rotary Handle

Product Dimension Drawing Fixed Type

H W W

SGM6 L L 125,160,250,400， 630,800/1000（3P/4P）

3P 4P

Front connection Front connection(mm) Note:All dimensions are in mm Note:All dimensions are in mm 75(3P)/100(4P) 25

SGM6/6S 55 111 116 134 172 90

125（3P/4P）

8 47 10

25 25 25

SGM6 Dimensions mm(L×W×H)

Frame Size 125

Length Length 133 133

3P 75 4P 100 Width Width

81 81 Height Height
