# EPBR-63M-H Series <!-- source-page:1 --> RCBO SERIES Residual Current Circuit Breakers with Overcurrent Protection <!-- source-page:2 --> Products Overview of Residual Current Protective Devices Product name RCBO | Product range | EPBR-63M/H | | --- | --- | | Product picture | | | Standard | IEC/EN 61009-1 | | --- | --- | | Number of poles | 1P+N | | Electrical characteristics | | | Rated current(A) In | 6~63 | | Rated voltage(V) | AC 230/240 | | Rated residual current(mA) | 10,30,100,300 | | Rated conditional shor-t circuit current(kA) | 6,10 | | Tripping curev | B,C | | Residual current operating characteristic | AC,A | | Catalogue page NO. | 25-28 | <!-- source-page:3 --> EPBR-63M/H Series Residual Current Circuit Breakers with Overcurrent Protection | Standard | | EN/IEC61009-1 | | --- | --- | --- | | Rated conditional shor-t circuit current(kA) | | 6,10 | | Rated current(A),ln | | 6,10,13,16,20,25,32,40,50,63 | | Number of poles | | 1P+N | | Rated sensitivity currents(mA),IΔn | | 10,30,100,300 | | Tripping curev | | B,C | | Rated residual non-operating current | | 0.5XIΔn | | Rated impulse withstand voltage Uimp(kV) | | 4 | | Rated voltage(V) | | AC 230/240 | | Ambient temperature (°C) | | -25~+40,Max.95%humidity | | Residual current off time | | ≤0.1s | | Type of trip | Ground fault | Electronic | | | Over current | Thermal-magnetic | | Electrical endurance | | 4000 | | Mechanical endurance | | 10000 | | Terminal capacity | | 10mm2 flexible/16mm2 rigid | | Protection degree | | IP20 | | Installation | | 35mm DIN rail | | Certification | | | | EPBR-63M EPBR-63H | | | <!-- source-page:4 --> Type AC Residual Current Circuit Breakers with Overcurrent Protection EPBR-63M Type A Rated current(A) IΔn Packing unit C curve B curve B curve C curve 6 EPBR-63M-B6/10 EPBR-63M-C6/10 EPBR-63M-B6/10-A EPBR-63M-C6/10-A 10 EPBR-63M-B10/10 EPBR-63M-C10/10 EPBR-63M-B10/10-A EPBR-63M-C10/10-A 13 EPBR-63M-B13/10 EPBR-63M-C13/10 EPBR-63M-B13/10-A EPBR-63M-C13/10-A 16 EPBR-63M-B16/10 EPBR-63M-C16/10 EPBR-63M-B16/10-A EPBR-63M-C16/10-A 20 EPBR-63M-B20/10 EPBR-63M-C20/10 EPBR-63M-B20/10-A EPBR-63M-C20/10-A 10mA 25 EPBR-63M-B25/10 EPBR-63M-C25/10 EPBR-63M-B25/10-A EPBR-63M-C25/10-A 32 EPBR-63M-B32/10 EPBR-63M-C32/10 EPBR-63M-B32/10-A EPBR-63M-C32/10-A 40 EPBR-63M-B40/10 EPBR-63M-C40/10 EPBR-63M-B40/10-A EPBR-63M-C40/10-A 50 EPBR-63M-B50/10 EPBR-63M-C50/10 EPBR-63M-B50/10-A EPBR-63M-C50/10-A 63 EPBR-63M-B63/10 EPBR-63M-C63/10 EPBR-63M-B63/10-A EPBR-63M-C63/10-A 6 EPBR-63M-B6/30 EPBR-63M-C6/30 EPBR-63M-B6/30-A EPBR-63M-C6/30-A 10 EPBR-63M-B10/30 EPBR-63M-C10/30 EPBR-63M-B10/30-A EPBR-63M-C10/30-A 13 EPBR-63M-B13/30 EPBR-63M-C13/30 EPBR-63M-B13/30-A EPBR-63M-C13/30-A 16 EPBR-63M-B16/30 EPBR-63M-C16/30 EPBR-63M-B16/30-A EPBR-63M-C16/30-A 20 EPBR-63M-B20/30 EPBR-63M-C20/30 EPBR-63M-B20/30-A EPBR-63M-C20/30-A 30mA 25 EPBR-63M-B25/30 EPBR-63M-C25/30 EPBR-63M-B25/30-A EPBR-63M-C25/30-A Type AC 32 EPBR-63M-B32/30 EPBR-63M-C32/30 EPBR-63M-B32/30-A EPBR-63M-C32/30-A 40 EPBR-63M-B40/30 EPBR-63M-C40/30 EPBR-63M-B40/30-A EPBR-63M-C40/30-A 50 EPBR-63M-B50/30 EPBR-63M-C50/30 EPBR-63M-B50/30-A EPBR-63M-C50/30-A 63 EPBR-63M-B63/30 EPBR-63M-C63/30 EPBR-63M-B63/30-A EPBR-63M-C63/30-A 6 6 EPBR-63M-B6/100 EPBR-63M-C6/100 EPBR-63M-B6/100-A EPBR-63M-C6/100-A 10 EPBR-63M-B10/100 EPBR-63M-C10/100 EPBR-63M-B10/100-A EPBR-63M-C10/100-A 13 EPBR-63M-B13/100 EPBR-63M-C13/100 EPBR-63M-B13/100-A EPBR-63M-C13/100-A 16 EPBR-63M-B16/100 EPBR-63M-C16/100 EPBR-63M-B16/100-A EPBR-63M-C16/100-A 20 EPBR-63M-B20/100 EPBR-63M-C20/100 EPBR-63M-B20/100-A EPBR-63M-C20/100-A 100mA 25 EPBR-63M-B25/100 EPBR-63M-C25/100 EPBR-63M-B25/100-A EPBR-63M-C25/100-A 32 EPBR-63M-B32/100 EPBR-63M-C32/100 EPBR-63M-B32/100-A EPBR-63M-C32/100-A 40 EPBR-63M-B40/100 EPBR-63M-C40/100 EPBR-63M-B40/100-A EPBR-63M-C40/100-A 50 EPBR-63M-B50/100 EPBR-63M-C50/100 EPBR-63M-B50/100-A EPBR-63M-C50/100-A 63 EPBR-63M-B63/100 EPBR-63M-C63/100 EPBR-63M-B63/100-A EPBR-63M-C63/100-A 6 EPBR-63M-B6/300 EPBR-63M-C6/300 EPBR-63M-B6/300-A EPBR-63M-C6/300-A Type A 10 EPBR-63M-B10/300 EPBR-63M-C10/300 EPBR-63M-B10/300-A EPBR-63M-C10/300-A 13 EPBR-63M-B13/300 EPBR-63M-C13/300 EPBR-63M-B13/300-A EPBR-63M-C13/300-A 16 EPBR-63M-B16/300 EPBR-63M-C16/300 EPBR-63M-B16/300-A EPBR-63M-C16/300-A 20 EPBR-63M-B20/300 EPBR-63M-C20/300 EPBR-63M-B20/300-A EPBR-63M-C20/300-A 300mA 25 EPBR-63M-B25/300 EPBR-63M-C25/300 EPBR-63M-B25/300-A EPBR-63M-C25/300-A 32 EPBR-63M-B32/300 EPBR-63M-C32/300 EPBR-63M-B32/300-A EPBR-63M-C32/300-A 40 EPBR-63M-B40/300 EPBR-63M-C40/300 EPBR-63M-B40/300-A EPBR-63M-C40/300-A 50 EPBR-63M-B50/300 EPBR-63M-C50/300 EPBR-63M-B50/300-A EPBR-63M-C50/300-A 63 EPBR-63M-B63/300 EPBR-63M-C63/300 EPBR-63M-B63/300-A EPBR-63M-C63/300-A <!-- source-page:5 --> Residual Current Circuit Breakers with Overcurrent Protection EPBR-63H | | Rated current(A) | IΔn | Type AC | | | | Type A | | | | Packing unit | | --- | --- | --- | --- | --- | --- | --- | --- | --- | --- | --- | --- | | | | | B curev | C curev | | | B curev | C curev | | | | | Type AC Type A | 6 | 10mA | EPBR-63H-B6/10 | EPBR-63H-C6/10 | | | EPBR-63H-B6/10-A | EPBR-63H-C6/10-A | | | 6 | | | 10 | | EPBR-63H-B10/10 | EPBR-63H-C10/10 | | | EPBR-63H-B10/10-A | EPBR-63H-C10/10-A | | | | | | 13 | | EPBR-63H-B13/10 | EPBR-63H-C13/10 | | | EPBR-63H-B13/10-A | EPBR-63H-C13/10-A | | | | | | 16 | | EPBR-63H-B16/10 | EPBR-63H-C16/10 | | | EPBR-63H-B16/10-A | EPBR-63H-C16/10-A | | | | | | 20 | | EPBR-63H-B20/10 | EPBR-63H-C20/10 | | | EPBR-63H-B20/10-A | EPBR-63H-C20/10-A | | | | | | 25 | | EPBR-63H-B25/10 | EPBR-63H-C25/10 | | | EPBR-63H-B25/10-A | EPBR-63H-C25/10-A | | | | | | 32 | | EPBR-63H-B32/10 | EPBR-63H-C32/10 | | | EPBR-63H-B32/10-A | EPBR-63H-C32/10-A | | | | | | 40 | | EPBR-63H-B40/10 | EPBR-63H-C40/10 | | | EPBR-63H-B40/10-A | EPBR-63H-C40/10-A | | | | | | 50 | | EPBR-63H-B50/10 | EPBR-63H-C50/10 | | | EPBR-63H-B50/10-A | EPBR-63H-C50/10-A | | | | | | 63 | | EPBR-63H-B63/10 | EPBR-63H-C63/10 | | | EPBR-63H-B63/10-A | EPBR-63H-C63/10-A | | | | | | 6 | 30mA | EPBR-63H-B6/30 | EPBR-63H-C6/30 | | | EPBR-63H-B6/30-A | EPBR-63H-C6/30-A | | | | | | 10 | | EPBR-63H-B10/30 | EPBR-63H-C10/30 | | | EPBR-63H-B10/30-A | EPBR-63H-C10/30-A | | | | | | 13 | | EPBR-63H-B13/30 | EPBR-63H-C13/30 | | | EPBR-63H-B13/30-A | EPBR-63H-C13/30-A | | | | | | 16 | | EPBR-63H-B16/30 | EPBR-63H-C16/30 | | | EPBR-63H-B16/30-A | EPBR-63H-C16/30-A | | | | | | 20 | | EPBR-63H-B20/30 | EPBR-63H-C20/30 | | | EPBR-63H-B20/30-A | EPBR-63H-C20/30-A | | | | | | 25 | | EPBR-63H-B25/30 | EPBR-63H-C25/30 | | | EPBR-63H-B25/30-A | EPBR-63H-C25/30-A | | | | | | 32 | | EPBR-63H-B32/30 | EPBR-63H-C32/30 | | | EPBR-63H-B32/30-A | EPBR-63H-C32/30-A | | | | | | 40 | | EPBR-63H-B40/30 | EPBR-63H-C40/30 | | | EPBR-63H-B40/30-A | EPBR-63H-C40/30-A | | | | | | 50 | | EPBR-63H-B50/30 | EPBR-63H-C50/30 | | | EPBR-63H-B50/30-A | EPBR-63H-C50/30-A | | | | | | 63 | | EPBR-63H-B63/30 | EPBR-63H-C63/30 | | | EPBR-63H-B63/30-A | EPBR-63H-C63/30-A | | | | | | 6 | 100mA | EPBR-63H-B6/100 | EPBR-63H-C6/100 | | | EPBR-63H-B6/100-A | EPBR-63H-C6/100-A | | | | | | 10 | | EPBR-63H-B10/100 | EPBR-63H-C10/100 | | | EPBR-63H-B10/100-A | EPBR-63H-C10/100-A | | | | | | 13 | | EPBR-63H-B13/100 | EPBR-63H-C13/100 | | | EPBR-63H-B13/100-A | EPBR-63H-C13/100-A | | | | | | 16 | | EPBR-63H-B16/100 | EPBR-63H-C16/100 | | | EPBR-63H-B16/100-A | EPBR-63H-C16/100-A | | | | | | 20 | | EPBR-63H-B20/100 | EPBR-63H-C20/100 | | | EPBR-63H-B20/100-A | EPBR-63H-C20/100-A | | | | | | 25 | | EPBR-63H-B25/100 | EPBR-63H-C25/100 | | | EPBR-63H-B25/100-A | EPBR-63H-C25/100-A | | | | | | 32 | | EPBR-63H-B32/100 | EPBR-63H-C32/100 | | | EPBR-63H-B32/100-A | EPBR-63H-C32/100-A | | | | | | 40 | | EPBR-63H-B40/100 | EPBR-63H-C40/100 | | | EPBR-63H-B40/100-A | EPBR-63H-C40/100-A | | | | | | 50 | | EPBR-63H-B50/100 | EPBR-63H-C50/100 | | | EPBR-63H-B50/100-A | EPBR-63H-C50/100-A | | | | | | 63 | | EPBR-63H-B63/100 | EPBR-63H-C63/100 | | | EPBR-63H-B63/100-A | EPBR-63H-C63/100-A | | | | | | 6 | 300mA | EPBR-63H-B6/300 | EPBR-63H-C6/300 | | | EPBR-63H-B6/300-A | EPBR-63H-C6/300-A | | | | | | 10 | | EPBR-63H-B10/300 | EPBR-63H-C10/300 | | | EPBR-63H-B10/300-A | EPBR-63H-C10/300-A | | | | | | 13 | | EPBR-63H-B13/300 | EPBR-63H-C13/300 | | | EPBR-63H-B13/300-A | EPBR-63H-C13/300-A | | | | | | 16 | | EPBR-63H-B16/300 | EPBR-63H-C16/300 | | | EPBR-63H-B16/300-A | EPBR-63H-C16/300-A | | | | | | 20 | | EPBR-63H-B20/300 | EPBR-63H-C20/300 | | | EPBR-63H-B20/300-A | EPBR-63H-C20/300-A | | | | | | 25 | | EPBR-63H-B25/300 | EPBR-63H-C25/300 | | | EPBR-63H-B25/300-A | EPBR-63H-C25/300-A | | | | | | 32 | | EPBR-63H-B32/300 | EPBR-63H-C32/300 | | | EPBR-63H-B32/300-A | EPBR-63H-C32/300-A | | | | | | 40 | | EPBR-63H-B40/300 | EPBR-63H-C40/300 | | | EPBR-63H-B40/300-A | EPBR-63H-C40/300-A | | | | | | 50 | | EPBR-63H-B50/300 | EPBR-63H-C50/300 | | | EPBR-63H-B50/300-A | EPBR-63H-C50/300-A | | | | | | 63 | | EPBR-63H-B63/300 | EPBR-63H-C63/300 | | | EPBR-63H-B63/300-A | EPBR-63H-C63/300-A | | | | <!-- source-page:6 --> EPBR-63M/H Series Residual Current Circuit Breakers with Overcurrent Protection Curves Breaking time of residual current Max.breaking time In(A) IΔn(A) IΔn 2 IΔn 5 IΔn 5-500A 6-63 0.01,0.03,0.1,0.3 0.1s 0.08s 0.04s 0.04s Wiring (The suitable conductors should be used for connection,see table below for relative parameters) Cross section area s(mm2) Tightening torque(N.m) Rated current In (A) 1 6 1.5 10 1.5 13 2.5 16-20 6 25 32 40-50 63 Types Both RCCBs and RCBOs are devided into types depending on the operating function: Type AC : For which tripping is ensured for residual sinusoidal alternating currents, whether suddenly applied or slowly rising. Type A : For which tripping is ensued for residual sinusoidal alternating currents and residual pulsating direct currents, whether suddenly applied or slowly rising. Tripping sensitivity data RCD with a rated residual current of maximum 30mA are used for personnel,material and fire protection, as well as for protection against direct contact. RCD with a rated residual current of maximum 300mA are used as preventative fire protection in case of insulation faults. RCD with a rated residual current of 100mA co-ordinated with the earth system according to the formula IΔn<50/R, to provide protection again indirect contacts. Overall and mounting dimensions 4 2.0 10 16 EPBR-63M/H
