# EPBR-32M-H Series

RCBO SERIES Residual Current Circuit Breakers with Overcurrent Protection

Products Overview of Residual Current Protective Devices

Product name

Product range

Product picture

Standard

Number of poles

Rated current(A) In

Rated voltage(V)

Rated residual current(mA)

Rated conditional short-circuit current(kA)

Tripping curve

Residual current operating characteristic

Catalogue page NO.

RCBO

EPBR-32M/H

IEC/EN 61009-1

1P+N

Electrical characteristics

6~32

AC 230/240

10,30,100,300

4.5,6

B,C

AC,A

33-36

EPBR-32M/H Series Residual Current Circuit Breakers with Overcurrent Protection Standard EN/IEC 61009-1 Rated conditional short-circuit current(kA) 4.5,6 Rated current(A),ln 6,10,13,16,20,25,32 Number of poles 1P+N Rated sensitivity currents(mA),IΔn 10,30,100,300 Tripping curve B,C Rated residual non-operating current 0.5XIΔn Rated impulse withstand voltage Uimp(kV) 4 Rated voltage(V) AC 230/240 Ambient temperature (°C) -25~+40,Max.95%humidity Residual current off time ≤0.1s

Type of trip

Electrical endurance 4000 Mechanical endurance 10000 Terminal capacity 10mm2 flexible/16mm2 rigid Protection degree IP20 Installation 35mm DIN rail

Ground fault Electronic Thermal-magnetic Over current

EPBR-32M EPBR-32H

Type AC Residual Current Circuit Breakers with Overcurrent Protection EPBR-32M Type A Rated current(A) IΔn Packing unit C curve B curve B curve C curve 6 EPBR-32M/B6/10 EPBR-32M/B6/10-A EPBR-32M/C6/10 EPBR-32M/C6/10-A 10 EPBR-32M/B10/10 EPBR-32M/B10/10-A EPBR-32M/C10/10 EPBR-32M/C10/10-A 13 EPBR-32M/B13/10 EPBR-32M/B13/10-A EPBR-32M/C13/10 EPBR-32M/C13/10-A 10mA 16 EPBR-32M/B16/10 EPBR-32M/B16/10-A EPBR-32M/C16/10 EPBR-32M/C16/10-A 20 EPBR-32M/B20/10 EPBR-32M/B20/10-A EPBR-32M/C20/10 EPBR-32M/C20/10-A 25 EPBR-32M/B25/10 EPBR-32M/B25/10-A EPBR-32M/C25/10 EPBR-32M/C25/10-A 32 EPBR-32M/B32/10 EPBR-32M/B32/10-A EPBR-32M/C32/10 EPBR-32M/C32/10-A 6 EPBR-32M/B6/30 EPBR-32M/B6/30-A EPBR-32M/C6/30 EPBR-32M/C6/30-A 10 EPBR-32M/B10/30 EPBR-32M/B10/30-A EPBR-32M/C10/30 EPBR-32M/C10/30-A 13 EPBR-32M/B13/30 EPBR-32M/B13/30-A EPBR-32M/C13/30 EPBR-32M/C13/30-A 30mA 16 EPBR-32M/B16/30 EPBR-32M/B16/30-A EPBR-32M/C16/30 EPBR-32M/C16/30-A Type AC 20 EPBR-32M/B20/30 EPBR-32MB20/30-A EPBR-32M/C20/30 EPBR-32M/C20/30-A 25 EPBR-32M/B25/30 EPBR-32M/B25/30-A EPBR-32M/C25/30 EPBR-32M/C25/30-A 32 EPBR-32M/B32/30 EPBR-32M/B32/30-A EPBR-32M/C32/30 EPBR-32M/C32/30-A 12 6 EPBR-32M/B6/100 EPBR-32M/B6/100-A EPBR-32M/C6/100 EPBR-32M/C6/100-A 10 EPBR-32M/B10/100 EPBR-32M/B10/100-A EPBR-32M/C10/100 EPBR-32M/C10/100-A 13 EPBR-32M/B13/100 EPBR-32M/B13/100-A EPBR-32M/C13/100 EPBR-32M/C13/100-A 16 EPBR-32M/B16/100 EPBR-32M/B16/100-A EPBR-32M/C16/100 EPBR-32M/C16/100-A 100mA 20 EPBR-32M/B20/100 EPBR-32M/B20/100-A EPBR-32M/C20/100 EPBR-32M/C20/100-A 25 EPBR-32M/B25/100 EPBR-32M/B25/100-A EPBR-32M/C25/100 EPBR-32M/C25/100-A 32 EPBR-32M/B32/100 EPBR-32M/B32/100-A EPBR-32M/C32/100 EPBR-32M/C32/100-A 6 EPBR-32M/B6/300 EPBR-32M/B6/300-A EPBR-32M/C6/300 EPBR-32M/C6/300-A Type A 10 EPBR-32M/B10/300 EPBR-32M/B10/300-A EPBR-32M/C10/300 EPBR-32M/C10/300-A 13 EPBR-32M/B13/300 EPBR-32M/B13/300-A EPBR-32M/C13/300 EPBR-32M/C13/300-A 16 EPBR-32M/B16/300 EPBR-32M/B16/300-A EPBR-32M/C16/300 EPBR-32M/C16/300-A 300mA 20 EPBR-32M/B20/300 EPBR-32M/B20/300-A EPBR-32M/C20/300 EPBR-32M/C20/300-A 25 EPBR-32M/B25/300 EPBR-32M/B25/300-A EPBR-32M/C25/300 EPBR-32M/C25/300-A 32 EPBR-32M/B32/300 EPBR-32M/B32/300-A EPBR-32M/C32/300 EPBR-32M/C32/300-A

[No machine-readable text on this page.]

EPBR-32M/H Series Residual Current Circuit Breakers with Overcurrent Protection Curves

Breaking time of residual current

Wiring (The suitable conductors should be used for connection,see table below for relative parameters)

Features Switching and isolation function. Protection against overload and short-circuit currents. Protection against the effects of sinusoidal alternating earth fault currents. Protection against indirect contacts and additional protection against direct contacts. Protection against fire hazard caused by insulation faults. Used in residential building and distribution boards. Overall and mounting dimensions

EPBR-32M/H

| In(A) | IΔn(A) | Max.breaking time IΔn 2 IΔn 5 IΔn 5A-500A |  |  |  |
| --- | --- | --- | --- | --- | --- |
|  |  |  | 2 IΔn | 5 IΔn | 5A-500A |
| 6-32 | 0.01,0.03,0.1,0.3 | 0.1s | 0.08s | 0.04s | 0.04s |

| Rated current In (A) | Cross section area s(mm2) | Tightening torque(N.m) |
| --- | --- | --- |
| 6 | 1 | 1.2 |
| 10 | 1.5 |  |
| 16-20 | 2.5 |  |
| 25 | 4 |  |
| 32 | 6 |  |
