# SGM6s-125

Thermal Adjustable Type SGM6s Moulded Case Circuit Breaker

Ratings And Specifications

Frame Size

Model SGM6s-125 Number of poles 3,4

Rated current(A) In

Magnetic tripping current (Ii) Thermo-adjustable setting Ir(xIn) 0.8/0.9/1.0 or 0.7/0.85/1.0 Standard IEC60947-2 Reference temperature 40℃/55℃ Rated operational voltage 380/400/415V AC Rated insulation voltage Ui (V) 800 Rated impluse withstand voltage Uimp (kV) 8 Breaking capacity level Rated ultimate short-circuit breaking capacity Icu(kA) Rated service short-circuit breaking capacity Ics(kA) lcu=Ics(kA)

Mechanical Endurance Electrical Endurance

Installation

M 25 18 18 for 16-100A 8500 1500

Thermal Adjustable Type

125

16,20,25,30, 32,40,50,60,63, 70,75,80,90,100, 125 10*In for 32 - 125 A 320 A for 16 - 30 A

Auxiliary contact(OF) Alarm switch(SD) Shunt tirp(MX) Under-voltage release(MN) AC Motor Mechanism Extended Rotary Handle

H 36 25 25 for 125A 7000 1000

Product Dimension Drawing Thermal Adjustable Type

H W W

SGM6s L L 125,160,250,400， 630,800,1000（3P/4P)

3P 4P Front connection Front connection(mm) Note:All dimensions are in mm Note:All dimensions are in mm 75(3P)/100(4P) 25

SGM6/6S 55 111 116 134 172 90

125（3P/4P）

8 47 10

25 25 25

SGM6 Dimensions mm(L×W×H)

Frame Size 125

Length Length 133 133

3P 75 4P 100 Width Width

81 81 Height Height
